The PVC Disc Pulverizer Machine is a high-performance size-reduction machine designed for grinding and pulverizing PVC and other suitable thermoplastic materials into fine, uniform powder. It is widely used in plastic recycling, PVC compounding, pipe manufacturing, profile manufacturing, cable industries, and other plastic-processing applications.
The machine works on the principle of high-speed rotating and stationary grinding discs. PVC material is fed into the grinding chamber, where it is subjected to intense impact, friction, and shearing forces between the discs. The material is progressively reduced to the required fine particle size and discharged through the outlet.
Key Features
* Heavy-duty construction for continuous industrial operation
* High-speed grinding system for efficient PVC pulverization
* Specially designed grinding discs for uniform particle size
* Adjustable grinding gap for controlling powder fineness
* Suitable for PVC scrap, sheets, profiles, pipes, and other compatible PVC materials
* High production capacity with comparatively low operating cost
* Easy feeding and material discharge arrangement
* Robust and compact machine design
* Easy access for cleaning, inspection, and disc replacement
* Low maintenance requirement
* Suitable for continuous production
* Optional cyclone, dust collection, and conveying systems can be integrated
Working Principle
PVC scrap or granules are fed into the pulverizer through the feeding hopper. The material enters the grinding chamber containing a rotating disc and a stationary disc.
The rotating disc operates at high speed, creating strong centrifugal, impact, friction, and shearing forces. As the PVC material passes through the controlled gap between the discs, it is progressively pulverized into fine particles.
The grinding clearance can be adjusted according to the desired output size. The pulverized PVC powder is then discharged from the machine and can be collected directly or transferred through a cyclone or pneumatic conveying system.
Applications
The PVC Disc Pulverizer is commonly used for:
* PVC pipe scrap recycling
* PVC profile scrap recycling
* PVC sheet grinding
* PVC flooring material
* PVC cable and insulation scrap
* PVC leather and artificial leather scrap
* Rigid PVC granules
* Suitable thermoplastic regrinding applications
* PVC powder preparation for manufacturing and compounding
Advantages
High Grinding Efficiency:
The high-speed disc arrangement provides effective grinding and helps achieve consistent powder quality.
Adjustable Fineness:
The grinding gap can be adjusted to obtain the required particle size depending on the material and application.
Strong and Durable Construction:
The machine is manufactured with a robust body and industrial-grade components for reliable operation.
Easy Maintenance:
The grinding chamber is designed to allow convenient inspection, cleaning, and replacement of wear parts.
Flexible Configuration:
The pulverizer can be supplied with accessories such as feeding systems, cyclone separators, dust collectors, and storage/collection arrangements.
Typical Machine Components
1. Feeding Hopper
2. Grinding Chamber
3. Rotating Grinding Disc
4. Stationary Grinding Disc
5. Main Shaft
6. Bearing Assembly
7. Drive Motor
8. Belt and Pulley/Drive Arrangement
9. Discharge Outlet
10. Machine Frame
11. Adjustable Grinding Mechanism
12. Optional Cyclone Separator
13. Optional Dust Collection System
Technical Specifications
Machine specifications can be customized according to the customer's material, required capacity, and powder fineness. Typical specifications include:
Material: PVC and suitable thermoplastic materials
Machine Type: Disc Pulverizer
Grinding System: High-speed disc grinding
Drive: Electric motor
Capacity: Available in different capacities according to model
Output Fineness: Adjustable according to application and material
Disc Material: Wear-resistant grade, selected according to application
Operation: Continuous
Feeding: Manual or automatic, depending on configuration
Discharge: Direct or cyclone-assisted
Control: Suitable electrical control panel
Optional Accessories
For a complete PVC pulverizing plant, the machine can be equipped with:
* Automatic feeding system
* Vibratory feeder
* Cyclone separator
* Dust collector/bag filter
* Pneumatic conveying system
* Rotary valve
* Magnetic separator
* Storage hopper
* Automatic packing system
* Electrical control panel
* Temperature monitoring system
Important Note:
Actual capacity, motor power, disc diameter, output fineness, and energy consumption depend on the type and condition of PVC material, moisture content, feed size, desired powder size, and operating conditions. Therefore, final machine specifications should be selected based on the customer's specific application.
The PVC Disc Pulverizer is an effective solution for converting suitable PVC scrap or feedstock into reusable fine powder, helping manufacturers incorporate recycled material into their production processes while reducing material waste.
